Busbar Application in Power Grid

Busbar Application in Power Grid

The proven quality of our products is based on internationally leading design and manufacturing concepts, combined with state-of-the-art production equipment. Our talented engineers have many years of experience in producing busbars.Whether our customers wish to develop a completely new solution, optimize a design or just produce their existing design under optimized conditions, we are your dedicated partner for laminated busbars.



Project: Yu-E HVDC light ±500KV Laminated Busbar

Parameter:

Voltage: 2200V DC

Current: 1250A

Dielectric Strength: 5.0 KV -AC-60s, No breakdown, no flicker.( Leakage Current ≤ 2mA)

Partial Discharge:<5PC @ 2000V AC


Project: “Zhoushan” DC Breaker ±200KV Laminated Busbar-274

Parameter:

Voltage: 4500V DC

Current: 200A

Dielectric Strength: 10KV -DC-60s, No breakdown, no flicker.

Partial discharge: ≤10PC @ 3600V AC

Project: “Xiamen” HVDC Light ±320KV Laminated Busbars

Parameters:

Voltage:2000V

Current: 500A

Project: Zhangbei HVDC Light ±500KV Laminated Busbar

Parameter:

Voltage : 2000V

Current: 800A

Dielectric Strength: 7.0 KV -AC-60s, No breakdown, no flicker.

( Leakage Current ≤ 3mA)

Partial Discharge: ≤10PC @ 1200V AC
